5VOI image
Deposition Date 2017-05-02
Release Date 2017-05-24
Last Version Date 2024-10-23
Entry Detail
PDB ID:
5VOI
Title:
X-ray crystal structure of bacterial RNA polymerase and pyrG promoter complex
Biological Source:
Method Details:
Experimental Method:
Resolution:
2.80 Å
R-Value Free:
0.23
R-Value Work:
0.19
R-Value Observed:
0.19
Space Group:
C 1 2 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA-directed RNA polymerase s
Chain IDs:A, B
Chain Length:315
Number of Molecules:2
Biological Source:Thermus thermophilus (strain HB27 / ATCC BAA-163 / DSM 7039)
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA-directed RNA polymerase s
Gene (Uniprot):rpoB
Chain IDs:C
Chain Length:1119
Number of Molecules:1
Biological Source:Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA-directed RNA polymerase s
Gene (Uniprot):rpoC
Chain IDs:D
Chain Length:1524
Number of Molecules:1
Biological Source:Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA-directed RNA polymerase s
Gene (Uniprot):rpoZ
Chain IDs:E
Chain Length:99
Number of Molecules:1
Biological Source:Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:RNA polymerase sigma factor S
Gene (Uniprot):sigA
Chain IDs:F
Chain Length:423
Number of Molecules:1
Biological Source:Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)
Polymer Type:polydeoxyribonucleotide
Molecule:PyrG promoter
Chain IDs:G
Chain Length:22
Number of Molecules:1
Biological Source:Bacillus subtilis
Polymer Type:polydeoxyribonucleotide
Molecule:PyrG promoter
Chain IDs:H
Chain Length:27
Number of Molecules:1
Biological Source:Bacillus subtilis
Primary Citation
X-ray crystal structure of a reiterative transcription complex reveals an atypical RNA extension pathway.
Proc. Natl. Acad. Sci. U.S.A. 114 8211 8216 (2017)
PMID: 28652344 DOI: 10.1073/pnas.1702741114

Abstact

Reiterative transcription is a noncanonical form of RNA synthesis in which a nucleotide specified by a single base in the DNA template is repetitively added to the nascent transcript. Here we determined the crystal structure of an RNA polymerase, the bacterial enzyme from Thermus thermophilus, engaged in reiterative transcription during transcription initiation at a promoter resembling the pyrG promoter of Bacillus subtilis The structure reveals that the reiterative transcript detours from the dedicated RNA exit channel and extends toward the main channel of the enzyme, thereby allowing RNA extension without displacement of the promoter recognition σ-factor. Nascent transcripts containing reiteratively added G residues are eventually extended by nonreiterative transcription, revealing an atypical pathway for the formation of a transcription elongation complex.
