3VRL image
Deposition Date 2012-04-12
Release Date 2013-04-17
Last Version Date 2024-10-30
Entry Detail
PDB ID:
3VRL
Keywords:
IMMUNE SYSTEM/VIRAL PROTEIN
Title:
Crystal structure of BMJ4 p24 capsid protein in complex with A10F9 Fab
Biological Source:
Source Organism(s):
Human immunodeficiency virus 1 (Taxon ID: 11676)
Mus musculus (Taxon ID: 10090)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
3.20 Å
R-Value Free:
0.29
R-Value Work:
0.21
R-Value Observed:
0.21
Space Group:
P 21 21 21
3VRL validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Gag protein
Gene (Uniprot):gag
Chain IDs:C, F (auth: D)
Chain Length:231
Number of Molecules:2
Biological Source:Human immunodeficiency virus 1
UniProt ID:Q9DGV7 Pfam ID:PF00607, PF19317
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:A10F9 Fab heavy chain
Chain IDs:A (auth: H), D (auth: E)
Chain Length:224
Number of Molecules:2
Biological Source:Mus musculus
UniProt ID:A0N7J2 Pfam ID:PF07686, PF07654
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:A10F9 Fab light chain
Chain IDs:B (auth: L), E (auth: F)
Chain Length:214
Number of Molecules:2
Biological Source:Mus musculus
UniProt ID:I6L978 Pfam ID:PF07686, PF07654
Ligand Molecules
NA
Primary Citation
Structure of the HIV-1 capsid protein p24 in complex with the broad-spectrum antibody A10F9
To be published ? ? ? (?)
Primary Citation of related structures
3VRL
