3KNW image
Deposition Date 2009-11-12
Release Date 2010-01-05
Last Version Date 2024-10-09
Entry Detail
PDB ID:
3KNW
Keywords:
transcription regulator
Title:
Crystal structure of a putative transcriptional regulator (TetR/AcrR family member) from putative transcriptional regulator (TetR/AcrR family)
Biological Source:
Source Organism(s):
Acinetobacter sp. (Taxon ID: 62977)
Expression System(s):
Escherichia coli bl21
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.45 Å
R-Value Free:
0.26
R-Value Work:
0.20
R-Value Observed:
0.21
Space Group:
P 21 21 21
3KNW validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Putative transcriptional regu
Gene (Uniprot):ACIAD2740
Chain IDs:A, B
Chain Length:212
Number of Molecules:2
Biological Source:Acinetobacter sp.
UniProt ID:Q6F8X8 Pfam ID:PF00440, PF16925
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Ligand Molecules
EDO
Primary Citation
Crystal structure of a putative transcriptional regulator (TetR/AcrR family member) from putative transcriptional regulator (TetR/AcrR family)
To be published ? ? ? (?)
