3KEU image
Deposition Date 2009-10-26
Release Date 2009-11-03
Last Version Date 2024-02-21
Entry Detail
PDB ID:
3KEU
Keywords:
TRANSFERASE
Title:
Crystal Structure of Human PL Kinase with bound PLP and ATP
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.10 Å
R-Value Free:
0.25
R-Value Work:
0.20
Space Group:
I 2 2 2
3KEU validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Pyridoxal kinase
Gene (Uniprot):PDXK
Chain IDs:A, B
Chain Length:312
Number of Molecules:2
Biological Source:Homo sapiens
UniProt ID:O00764 Pfam ID:PF08543 EC:2.7.1.35
Ligand Molecules
ATP
MG
MPD
NA
PLP
SO4
Primary Citation
Crystal structure of PL kinase in complex with MgATP and PLP: Structural basis of severe induced MgATP substrate inhibition of the enzyme
To be published ? ? ? (?)
Primary Citation of related structures
2YXT
