3EDC image
Deposition Date 2008-09-03
Release Date 2008-11-25
Last Version Date 2023-11-01
Entry Detail
PDB ID:
3EDC
Keywords:
Title:
Crystal Structure of a 1.6-hexanediol Bound Tetrameric Form of Escherichia coli Lac-repressor Refined to 2.1 Resolution
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.10 Å
R-Value Free:
0.20
R-Value Work:
0.15
R-Value Observed:
0.15
Space Group:
C 1 2 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Lactose operon repressor
Gene (Uniprot):lacI
Chain IDs:A, B, C, D
Chain Length:360
Number of Molecules:4
Biological Source:Escherichia coli K12
Ligand Molecules
Primary Citation
Crystal structure of a 1.6-hexanediol bound tetrameric form of Escherichia coli lac-repressor refined to 2.1 A resolution
Proteins 75 748 759 (2009)
PMID: 19004002 DOI: 10.1002/prot.22284

Abstact

We report the structure of a novel tetrameric form of the lactose repressor (LacI) protein from Escherichia coli refined to 2.1 A resolution. The tetramer is bound to 1.6-hexanediol present in the crystallization solution and the final R(free) for the structure is 0.201. The structure confirms previously reported structures on the monomer level. However, the tetramer is much more densely packed. This adds a new level of complexity to the interpretation of mutational effects and challenges details in the current model for LacI function. Several amino acids, previously associated with changes in function but unexplained at the structural level, appear in a new structural context in this tetramer which provides new implications for their function.
