38KM image
Deposition Date 2026-08-31
Release Date 2026-09-09
Last Version Date 2026-09-09
Entry Detail
PDB ID:
38KM
Keywords:
STRUCTURAL PROTEIN
Title:
Cofilactin filament with two AIP1 bound to middle of the filament
Biological Source:
Source Organism(s):
Caenorhabditis elegans (Taxon ID: 6239)
Oryctolagus cuniculus (Taxon ID: 9986)
Expression System(s):
Escherichia coli 'bl21-gold(de3)plyss ag'
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
2.30 Å
Aggregation State:
FILAMENT
Reconstruction Method:
SINGLE PARTICLE
38KM validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Actin, alpha skeletal muscle
Gene (Uniprot):ACTA1
Chain IDs:A, B, C, D, E, F, G, H
Chain Length:152
Number of Molecules:8
Biological Source:Oryctolagus cuniculus
UniProt ID:P68135 Pfam ID:PF00022
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Actin-interacting protein 1
Gene (Uniprot):unc-78
Chain IDs:I (auth: X), J (auth: Y)
Chain Length:611
Number of Molecules:2
Biological Source:Caenorhabditis elegans
UniProt ID:Q11176 Pfam ID:PF00400
Polymer Type:polypeptide(L)
Molecule:Cofilin
Chain IDs:K (auth: a), L (auth: b), M (auth: c), N (auth: d), O (auth: e), P (auth: f)
Chain Length:152
Number of Molecules:6
Biological Source:Caenorhabditis elegans
Ligand Molecules
ADP
MG
Primary Citation
AIP1 Promotes Severing of Cofilin-Decorated Actin Filaments by Creating a Stress-Sensitive Rigid-Compliant Boundary
To Be Published ? ? ? (?)
Primary Citation of related structures
38KM
