33SD image
Deposition Date 2026-08-21
Release Date 2026-10-14
Last Version Date 2026-10-14
Entry Detail
PDB ID:
33SD
Keywords:
Title:
Immune complex comprising the HRSV preF trimer (SC-DM) and the monoclonal antibody Lor69 - Obtained by cryo-EM
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
3.30 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Fusion glycoprotein F0
Gene (Uniprot):F
Chain IDs:A, D (auth: B), G (auth: C)
Chain Length:522
Number of Molecules:3
Biological Source:Respiratory syncytial virus
Polymer Type:polypeptide(L)
Molecule:Lor69 Heavy Chain
Chain IDs:B (auth: H), E (auth: D), H (auth: E)
Chain Length:121
Number of Molecules:3
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:Lor69 Light Chain
Chain IDs:C (auth: L), F, I (auth: G)
Chain Length:107
Number of Molecules:3
Biological Source:Homo sapiens
Ligand Molecules
Primary Citation
Distinct mechanisms of neutralization by antibodies targeting a conserved pneumovirus F epitope.
Biorxiv ? ? ? (2026)
PMID: 42818254 DOI: 10.64898/2026.09.21.749132

Abstact

Pneumoviruses cause seasonal outbreaks leading to hospitalizations of vulnerable populations such as infants and the elderly. Cross-neutralizing antibodies targeting viral fusion have been isolated from infected individuals, but their elicitation and mechanisms of action remain understudied. Here, we describe two vaccine-elicited antibody classes, LOR24 and LOR69, that bind an overlapping epitope, and identify the somatic mutations that endow their breadth and potency, respectively. Cryo-electron microscopy structures of both antibodies bound to the HRSV fusion (F) protein show binding modes distinct from each other and from the previously described cross-neutralizing antibody MPE8, yet they all use similar motifs for binding. Complementary in vitro and electron microscopy experiments show that these antibodies either lock prefusion F as a trimer, arrest F in a monomeric or intermediate state, or promote the transition to the postfusion conformation. This work sheds light on mechanisms of pneumovirus neutralization and the elicitation of cross-neutralizing antibody responses.
