2ZAD image
Deposition Date 2007-10-03
Release Date 2008-04-08
Last Version Date 2024-10-16
Entry Detail
PDB ID:
2ZAD
Keywords:
ISOMERASE
Title:
Crystal Structure of Muconate Cycloisomerase from Thermotoga maritima MSB8
Biological Source:
Source Organism(s):
Thermotoga maritima (Taxon ID: 243274)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.60 Å
R-Value Free:
0.20
R-Value Work:
0.17
R-Value Observed:
0.17
Space Group:
P 4
2ZAD validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Muconate cycloisomerase
Gene (Uniprot):TM_0006
Chain IDs:A, B, C, D
Chain Length:345
Number of Molecules:4
Biological Source:Thermotoga maritima
UniProt ID:Q9WXM1 Pfam ID:PF13378, PF02746 EC:5.5.1.1
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Ligand Molecules
1PE
MN
PEG
Primary Citation
Crystal Structure of Muconate Cycloisomerase from Thermotoga maritima MSB8
To be published ? ? ? (?)
Primary Citation of related structures
2ZAD
