ISDA: 28JR

Deposition Date 2026-02-03

Release Date 2026-07-22

Last Version Date 2026-07-22

Entry Detail

PDB ID:

28JR

Keywords:

MEMBRANE PROTEIN

Title:

Encounter Complex: BAM bound BepA

Biological Source:

Source Organism(s):

Escherichia coli (Taxon ID: 562)

Expression System(s):

Escherichia coli bl21(de3)

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

5.30 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Outer membrane protein assemb
Gene (Uniprot):bamA
Chain IDs:D (auth: A)
Chain Length:790
Number of Molecules:1
Biological Source:Escherichia coli

UniProt ID:P0A940 Pfam ID:PF07244, PF01103

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Outer membrane protein assemb
Gene (Uniprot):bamB
Chain IDs:E (auth: B)
Chain Length:373
Number of Molecules:1
Biological Source:Escherichia coli

UniProt ID:P77774 Pfam ID:PF13360

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Outer membrane protein assemb
Gene (Uniprot):bamC
Chain IDs:A (auth: C)
Chain Length:320
Number of Molecules:1
Biological Source:Escherichia coli

UniProt ID:P0A903 Pfam ID:PF06804

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Outer membrane protein assemb
Gene (Uniprot):bamD
Chain IDs:B (auth: D)
Chain Length:226
Number of Molecules:1
Biological Source:Escherichia coli

UniProt ID:P0AC02 Pfam ID:PF13525

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Outer membrane protein assemb
Gene (Uniprot):bamE
Chain IDs:C (auth: E)
Chain Length:104
Number of Molecules:1
Biological Source:Escherichia coli

UniProt ID:P0A937 Pfam ID:PF04355

Structures with similar UniProt ID

Structural Superimposition Protein Blast

Polymer Type:polypeptide(L)
Molecule:Beta-barrel assembly-enhancin
Gene (Uniprot):bepA
Chain IDs:F
Chain Length:492
Number of Molecules:1
Biological Source:Escherichia coli

UniProt ID:P66948 Pfam ID:PF01435, PF14559 EC:3.4.-.-

Ligand Molecules

Primary Citation

BAM-BepA complexes in outer membrane protein quality control.

Fenn, K.L, Higgins, V, Machin, J.M, Calabrese, A.N, Berry, A, Radford, S.E, Ranson, N.A.Show

Nat Commun ? ? ? (2026)

PMID: 42426009 DOI: 10.1038/s41467-026-75227-x
