25RY image
Deposition Date 2026-04-16
Release Date 2026-10-07
Last Version Date 2026-10-07
Entry Detail
PDB ID:
25RY
Keywords:
TRANSFERASE
Title:
Cryo-EM structure of the E. coli beta sliding clamp-Hda heterooctamer
Biological Source:
Source Organism(s):
Escherichia coli (Taxon ID: 562)
Expression System(s):
Escherichia coli bl21
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.12 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
25RY validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Beta sliding clamp
Gene (Uniprot):dnaN
Chain IDs:A, B, C, D
Chain Length:387
Number of Molecules:4
Biological Source:Escherichia coli
UniProt ID:P0A990 Pfam ID:PF00712, PF02767, PF02768
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:DnaA regulatory inactivator H
Gene (Uniprot):hda
Chain IDs:E, F, G, H
Chain Length:233
Number of Molecules:4
Biological Source:Escherichia coli
UniProt ID:P69931 Pfam ID:PF00308, PF22688
Ligand Molecules
ADP
MG
Primary Citation
Reversible autoinhibition of the bacterial replication-licensing Hda-beta clamp complex.
Nucleic Acids Res. ? ? ? (2026)
Primary Citation of related structures
25RY
