22XM image
Deposition Date 2026-01-27
Release Date 2026-03-11
Last Version Date 2026-03-18
Entry Detail
PDB ID:
22XM
Title:
MexBYB-Ka symmetry-like
Biological Source:
Source Organism(s):
Method Details:
Experimental Method:
Resolution:
3.55 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:MexBYB
Chain IDs:A (auth: B), B (auth: C), C (auth: A)
Chain Length:1049
Number of Molecules:3
Biological Source:Pseudomonas aeruginosa
Ligand Molecules
Primary Citation
Cryo-EM structures of a MexB-MexY chimeric efflux pump reveal that large open clefts are intrinsic to the MexY porter domain.
Acta Crystallogr. Sect. F Struct. Biol. Cryst. Commun. 82 83 93 (2026)
PMID: 41744473 DOI: 10.1107/S2053230X26001202

Abstact

RND-type multidrug-efflux pumps are major contributors to multidrug resistance in Gram-negative bacteria, with MexY from Pseudomonas aeruginosa playing a central role in aminoglycoside resistance. Unlike other RND transporters, MexY exhibits unusually large open clefts in the binding and extrusion states. To determine whether this feature is intrinsic to its drug-recognition porter domain, we created a chimeric protein, MexBYB, by replacing the funnel-like and transmembrane domains of MexY with those of the homologous transporter MexB, and determined its structures by cryoEM under apo and kanamycin-supplemented conditions. Under both conditions, MexBYB was reported to adopt symmetric-like and asymmetric conformations. Structural comparisons reveal that the unusually large open clefts are retained in MexBYB, indicating that this feature is intrinsic to the MexY porter domain.
