22EA image
Deposition Date 2026-01-07
Release Date 2026-09-02
Last Version Date 2026-09-02
Entry Detail
PDB ID:
22EA
Keywords:
VIRAL PROTEIN
Title:
Cryo-EM structure of MERS-CoV S protein bound with receptor DPP4 in the conformation 3 (3 up RBD and 3 DPP4 bound).
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Middle East respiratory syndrome-related coronavirus (isolate United Kingdom/H123990006/2012) (Taxon ID: 1263720)
Expression System(s):
Homo sapiens
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.44 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
22EA validation report missing
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Dipeptidyl peptidase 4 membra
Chain IDs:A (auth: D), B (auth: E), D (auth: F), E (auth: G), G (auth: A), H (auth: B)
Chain Length:791
Number of Molecules:6
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:Spike glycoprotein
Chain IDs:C (auth: H), F (auth: I), I (auth: C)
Chain Length:1340
Number of Molecules:3
Biological Source:Middle East respiratory syndrome-related coronavirus (isolate United Kingdom/H123990006/2012)
Ligand Molecules
NA
Primary Citation
Cryo-EM structure of MERS-CoV S protein bound with receptor DPP4 in the conformation 3 (3 up RBD and 3 DPP4 bound).
To Be Published ? ? ? (?)
Primary Citation of related structures
22EA
