22DY image
Deposition Date 2026-01-07
Release Date 2026-09-02
Last Version Date 2026-09-02
Entry Detail
PDB ID:
22DY
Keywords:
VIRAL PROTEIN
Title:
Local structure of MERS-CoV S protein bound with receptor DPP4 in the conformation 2 (2 up RBD and 2 DPP4 bound)
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Middle East respiratory syndrome-related coronavirus (isolate United Kingdom/H123990006/2012) (Taxon ID: 1263720)
Expression System(s):
Homo sapiens
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.35 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
22DY validation report missing
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Dipeptidyl peptidase 4 membra
Chain IDs:A (auth: D), B (auth: E), D (auth: A), E (auth: B)
Chain Length:791
Number of Molecules:4
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:Spike glycoprotein
Chain IDs:C (auth: H), F, G (auth: C)
Chain Length:1340
Number of Molecules:3
Biological Source:Middle East respiratory syndrome-related coronavirus (isolate United Kingdom/H123990006/2012)
Ligand Molecules
NA
Primary Citation
Cryo-EM structure of MERS-CoV S protein bound with receptor DPP4 in the conformation2(2 up RBD and 2 DPP4 bound)
To Be Published ? ? ? (?)
Primary Citation of related structures
22DY
