1PXW image
Deposition Date 2003-07-07
Release Date 2004-01-27
Last Version Date 2024-02-14
Entry Detail
PDB ID:
1PXW
Keywords:
Title:
Crystal structure of L7Ae sRNP core protein from Pyrococcus abyssii
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
1.94 Å
R-Value Free:
0.27
R-Value Work:
0.22
R-Value Observed:
0.22
Space Group:
P 21 21 2
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:LSU ribosomal protein L7AE
Gene (Uniprot):rpl7ae
Chain IDs:A, B
Chain Length:128
Number of Molecules:2
Biological Source:Pyrococcus abyssi
Primary Citation
Purification, crystallization and preliminary X-ray diffraction data of L7Ae sRNP core protein from Pyrococcus abyssii.
Acta Crystallogr.,Sect.D 60 122 124 (2004)
PMID: 14684904 DOI: 10.1107/S090744490302239X

Abstact

The L7Ae sRNP core protein from Pyrococcus abyssii was crystallized using the sitting-drop vapour-diffusion method. Crystals were obtained in the presence of MgCl(2), PEG 2000 MME and acetate buffer at pH 4.0. A native data set has been collected at 2.9 A resolution using a rotating-anode generator at room temperature. Crystals belong to the orthorhombic space group P2(1)2(1)2, with unit-cell parameters a = 70.7, b = 112.9, c = 34.8 A. There are two monomers of MW 14 200 Da per asymmetric unit and the packing density V(M) is 2.45 A(3) Da(-1). A molecular-replacement analysis gave solutions for the rotation and translation functions.
