Abstact

Apical membrane antigen 1 of the malarial parasite Plasmodium falciparum (Pf AMA1) is a merozoite antigen that is considered a strong candidate for inclusion in a malaria vaccine. Antibodies reacting with disulphide bond-dependent epitopes in AMA1 block invasion of host erythrocytes by P.falciparum merozoites, and we show here that epitopes involving sites of mutations in domain III are targets of inhibitory human antibodies. The solution structure of AMA1 domain III, a 14kDa protein, has been determined using NMR spectroscopy on uniformly 15N and 13C/15N-labelled samples. The structure has a well-defined disulphide-stabilised core region separated by a disordered loop, and both the N and C-terminal regions of the molecule are unstructured. Within the disulphide-stabilised core, residues 443-447 form a turn of helix and residues 495-498 and 503-506 an anti-parallel beta-sheet with a distorted type I beta-turn centred on residues 500-501, producing a beta-hairpin-type structure. The structured region of the molecule includes all three disulphide bonds. The previously unassigned connectivities for two of these bonds could not be established with certainty from the NMR data and structure calculations, but were determined to be C490-C507 and C492-C509 from an antigenic analysis of mutated forms of this domain expressed using phage display. Naturally occurring mutations in domain III that are located far apart in the primary sequence tend to cluster in the region of the disulphide core in the three-dimensional structure of the molecule. The structure shows that nearly all the polymorphic sites have a high level of solvent accessibility, consistent with their location in epitopes recognised by protective antibodies. Even though domain III in solution contains significant regions of disorder in the structure, the disulphide-stabilised core that is structured is clearly an important element of the antigenic surface of AMA1 recognised by protective antibodies.
