13HA image
Deposition Date 2026-05-05
Release Date 2026-09-30
Last Version Date 2026-09-30
Entry Detail
PDB ID:
13HA
Keywords:
Title:
The structure of Fab_C1 in complex with CD30
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.00 Å
R-Value Free:
0.22
R-Value Work:
0.18
R-Value Observed:
0.19
Space Group:
P 31 2 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Tumor necrosis factor recepto
Gene (Uniprot):TNFRSF8
Chain IDs:C (auth: A)
Chain Length:0
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:FabS1CE2_C1 heavy chain
Mutagens:K123Q and E154G
Chain IDs:A (auth: B)
Chain Length:0
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:FabS1CE2_C1 light chain (Tras
Chain IDs:B (auth: C)
Chain Length:0
Number of Molecules:1
Biological Source:Homo sapiens
Primary Citation
Strategy for modular assembly of tetravalent, multispecific antibodies.
Protein Sci. 35 e70797 e70797 (2026)
PMID: 42757708 DOI: 10.1002/pro.70797

Abstact

Multispecific, multivalent antibodies (Abs) are a burgeoning class of drugs that dramatically expand the pharmacological repertoire beyond traditional therapeutic Abs. Here, we present a simple, modular approach to developing multispecific, multivalent Abs based on a Fab-phage library with a single light chain. Using this library, we created three Abs targeting unique sites on programmed death-ligand 1 (PD-L1) and another antibody targeting CD30. Biophysical and cellular characterization of these Abs demonstrated their functional equivalence to clinically relevant Abs targeting PD-L1 or CD30. We then combined these paratopes into a series of bispecific, tetravalent, triparatopic Abs that retained the functionality of the parental Abs. Structural analysis of each of the Abs in complex with their cognate antigens demonstrated the adaptability of the common light chain to form diverse paratopes with an array of distinct heavy chains.
