13DV image
Deposition Date 2026-05-01
Release Date 2026-10-07
Last Version Date 2026-10-07
Entry Detail
PDB ID:
13DV
Keywords:
SIGNALING PROTEIN
Title:
BRAF/CRAF/MEK1/14-3-3 complex
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Spodoptera frugiperda (Taxon ID: 7108)
Expression System(s):
Spodoptera frugiperda
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.90 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
13DV validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Serine/threonine-protein kina
Gene (Uniprot):BRAF
Chain IDs:A
Chain Length:354
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P15056 Pfam ID:PF07714 EC:2.7.10.2
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:RAF proto-oncogene serine/thr
Gene (Uniprot):RAF1
Mutagens:Y340D, Y341D, F559E, R563A
Chain IDs:B
Chain Length:367
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P04049 Pfam ID:PF07714 EC:2.7.10.2
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Dual specificity mitogen-acti
Gene (Uniprot):MAP2K1
Mutagens:S218A, S222A
Chain IDs:C
Chain Length:420
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q02750 Pfam ID:PF00069 EC:2.7.12.2
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:14-3-3 protein epsilon
Gene (Uniprot):LOC118274546
Chain IDs:D (auth: X)
Chain Length:262
Number of Molecules:1
Biological Source:Spodoptera frugiperda
UniProt ID:A0A2H1VA22
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:14-3-3 protein zeta
Gene (Uniprot):LOC118271767
Chain IDs:E (auth: Y)
Chain Length:247
Number of Molecules:1
Biological Source:Spodoptera frugiperda
UniProt ID:A0A9R0D7T1
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
SEP A, B SER modified residue
Ligand Molecules
29L
LCJ
Primary Citation
Complex structure of BRAF/CRAF/MEK1/14-3-3
To Be Published ? ? ? (?)
Primary Citation of related structures
13DV
