12BY image
Deposition Date 2026-03-26
Release Date 2026-07-08
Last Version Date 2026-07-08
Entry Detail
PDB ID:
12BY
Keywords:
STRUCTURAL PROTEIN
Title:
Gelsolin domain G2G3 fully bound to F-actin
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Oryctolagus cuniculus (Taxon ID: 9986)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
2.76 Å
Aggregation State:
FILAMENT
Reconstruction Method:
SINGLE PARTICLE
12BY validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Actin, alpha skeletal muscle
Gene (Uniprot):ACTA1
Chain IDs:A, B, C, D, E, F, G, H
Chain Length:377
Number of Molecules:8
Biological Source:Oryctolagus cuniculus
UniProt ID:P68135 Pfam ID:PF00022 EC:3.6.4.-
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Gelsolin
Gene (Uniprot):GSN
Chain IDs:I
Chain Length:246
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P06396 Pfam ID:PF00626
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
HIC A HIS modified residue
Ligand Molecules
ADP
CA
MG
Primary Citation
Domains G2G3 Prime the Actin Filament for Severing by Gelsolin
To Be Published ? ? ? (?)
Primary Citation of related structures
12BY
