11MP image
Deposition Date 2026-03-05
Release Date 2026-07-15
Last Version Date 2026-07-15
Entry Detail
PDB ID:
11MP
Keywords:
METAL BINDING PROTEIN
Title:
E. coli SufE bound to SufBC2D
Biological Source:
Source Organism(s):
Escherichia coli (Taxon ID: 562)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
4.21 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
11MP validation report missing
Macromolecular Entities
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Probable ATP-dependent transp
Gene (Uniprot):sufC
Chain IDs:C (auth: A), D (auth: B)
Chain Length:248
Number of Molecules:2
Biological Source:Escherichia coli
UniProt ID:P77499 Pfam ID:PF00005
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Iron-sulfur cluster assembly
Gene (Uniprot):sufB
Mutagens:Y224A
Chain IDs:A (auth: C)
Chain Length:510
Number of Molecules:1
Biological Source:Escherichia coli
UniProt ID:P77522 Pfam ID:PF19295, PF01458
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Iron-sulfur cluster assembly
Gene (Uniprot):sufD
Chain IDs:E (auth: D)
Chain Length:423
Number of Molecules:1
Biological Source:Escherichia coli
UniProt ID:P77689 Pfam ID:PF01458
Structures with similar UniProt ID
Structural Superimposition Protein Blast
Polymer Type:polypeptide(L)
Molecule:Cysteine desulfuration protei
Gene (Uniprot):sufE
Chain IDs:B (auth: E)
Chain Length:138
Number of Molecules:1
Biological Source:Escherichia coli
UniProt ID:P76194 Pfam ID:PF02657
Ligand Molecules
NA
Primary Citation
The structure of the SufBC 2 D-SufE complex reveals the mechanism of sulfur transfer in bacterial Fe-S cluster assembly.
Biorxiv ? ? ? (2026)
PMID: 42239212 DOI: 10.64898/2026.05.18.725997
Primary Citation of related structures
11MP
