9XWU image
Deposition Date 2025-11-28
Release Date 2026-04-15
Last Version Date 2026-04-22
Entry Detail
PDB ID:
9XWU
Keywords:
Title:
Crystal structure of E.coli CDP-diacylglycerol pyrophosphatase (Cdh) complexed with AMP
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.00 Å
R-Value Free:
0.25
R-Value Work:
0.21
Space Group:
P 1 21 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:CDP-diacylglycerol pyrophosph
Gene (Uniprot):cdh
Chain IDs:A, B
Chain Length:259
Number of Molecules:2
Biological Source:Escherichia coli K-12
Ligand Molecules
Primary Citation
Structural mechanism of membrane-associated cytidine diphosphate diacylglycerol diphosphatase in Escherichia coli.
Int. J. Biol. Macromol. 359 151839 151839 (2026)
PMID: 41946407 DOI: 10.1016/j.ijbiomac.2026.151839

Abstact

Cytidine diphosphate diacylglycerol (CDP-DAG) diphosphatase (Cdh) regulates phospholipid biosynthesis by hydrolyzing CDP-DAG into cytidine monophosphate (CMP) and phosphatidic acid (PA), thereby maintaining the steady-state cellular levels of these key metabolic intermediates. Although CDP-DAG serves as a universal branch point in phospholipid metabolism across all three domains of life, Cdh is found predominantly in prokaryotes and, to a lesser extent, in eukaryotes. In Escherichia coli, Cdh is a membrane-associated enzyme belonging to the histidine-triad (HIT)-like hydrolase family and functions independently of metal ions. Here, we report two X-ray crystal structures of E. coli Cdh in complex with a reaction product, CMP, and an inhibitor, AMP, revealing the molecular basis of nucleotide recognition and substrate binding. Integrating structural and biochemical analyses, we identify a pair of conserved histidine residues, His-140 and His-142, as key catalytic determinants. Furthermore, we demonstrate that Cdh adopts a bitopic membrane topology, in which an N-terminal transmembrane helix spans the lipid bilayer and serves as the primary membrane anchor, positioning the catalytic domain at the membrane interface. Together, these findings establish Cdh as a monomeric, membrane-embedded HIT-like hydrolase and provide mechanistic insight into CDP-DAG turnover at the membrane-cytosol interface.
