ISDA: 9NUW

Deposition Date 2025-03-19

Release Date 2026-04-01

Last Version Date 2026-04-01

Entry Detail

PDB ID:

9NUW

Keywords:

REPLICATION

Title:

SsoPfMCM:DNA class 2a from DNA 2

Biological Source:

Source Organism(s):

Saccharolobus solfataricus P2 (Taxon ID: 273057)
synthetic construct (Taxon ID: 32630)

Expression System(s):

Escherichia coli

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

2.65 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Minichromosome maintenance pr
Gene (Uniprot):PF0482, MCM
Chain IDs:A, B, C, D, E, F
Chain Length:613
Number of Molecules:6
Biological Source:Saccharolobus solfataricus P2

UniProt ID:Q9UXG1,Q8U3I4 Pfam ID:PF14551, PF17207, PF00493, PF17855 EC:3.6.4.12

Polymer Type:polydeoxyribonucleotide
Molecule:DNA (60-MER)
Chain IDs:G (auth: X), H (auth: Y)
Chain Length:60
Number of Molecules:2
Biological Source:synthetic construct

Ligand Molecules
