ISDA: 9NUM

Deposition Date 2025-03-19

Release Date 2026-03-25

Last Version Date 2026-03-25

Entry Detail

PDB ID:

9NUM

Keywords:

REPLICATION, HYDROLASE/DNA

Title:

SsoPfMCM:DNA class 3 from merged particles

Biological Source:

Source Organism(s):

Saccharolobus solfataricus P2 (Taxon ID: 273057)
Pyrococcus furiosus DSM 3638 (Taxon ID: 186497)
synthetic construct (Taxon ID: 32630)

Expression System(s):

Escherichia coli

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.67 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Minichromosome maintenance pr
Gene (Uniprot):MCM
Chain IDs:A, B, C, D, E, F, G
Chain Length:613
Number of Molecules:7
Biological Source:Saccharolobus solfataricus P2, Pyrococcus furiosus DSM 3638

UniProt ID:Q9UXG1 Pfam ID:PF14551, PF17207, PF00493, PF17855 EC:3.6.4.12

Polymer Type:polydeoxyribonucleotide
Molecule:DNA (60-MER)
Chain IDs:H (auth: X), I (auth: Y)
Chain Length:60
Number of Molecules:2
Biological Source:synthetic construct

Ligand Molecules

ADP

Primary Citation

SsoPfMCM:DNA class 3 from merged particles

Enemark, E.J, Rasouli, S, Myasnikov, A.Show

To Be Published ? ? ? (?)

Primary Citation of related structures
