5XWY image
Deposition Date 2017-06-30
Release Date 2017-09-13
Last Version Date 2025-07-02
Entry Detail
PDB ID:
5XWY
Title:
Electron cryo-microscopy structure of LbuCas13a-crRNA binary complex
Biological Source:
Method Details:
Experimental Method:
Resolution:
3.20 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:A type VI-A CRISPR-Cas RNA-gu
Gene (Uniprot):cas13a
Mutagens:R1048A, H1053A
Chain IDs:A
Chain Length:1159
Number of Molecules:1
Biological Source:Leptotrichia buccalis (strain ATCC 14201 / DSM 1135 / JCM 12969 / NCTC 10249 / C-1013-b)
Polymer Type:polyribonucleotide
Molecule:RNA (59-MER)
Chain IDs:B
Chain Length:59
Number of Molecules:1
Biological Source:synthetic construct
Ligand Molecules
Primary Citation
The Molecular Architecture for RNA-Guided RNA Cleavage by Cas13a.
Cell 170 714 726.e10 (2017)
PMID: 28757251 DOI: 10.1016/j.cell.2017.06.050

Abstact

Cas13a, a type VI-A CRISPR-Cas RNA-guided RNA ribonuclease, degrades invasive RNAs targeted by CRISPR RNA (crRNA) and has potential applications in RNA technology. To understand how Cas13a is activated to cleave RNA, we have determined the crystal structure of Leptotrichia buccalis (Lbu) Cas13a bound to crRNA and its target RNA, as well as the cryo-EM structure of the LbuCas13a-crRNA complex. The crRNA-target RNA duplex binds in a positively charged central channel of the nuclease (NUC) lobe, and Cas13a protein and crRNA undergo a significant conformational change upon target RNA binding. The guide-target RNA duplex formation triggers HEPN1 domain to move toward HEPN2 domain, activating the HEPN catalytic site of Cas13a protein, which subsequently cleaves both single-stranded target and collateral RNAs in a non-specific manner. These findings reveal how Cas13a of type VI CRISPR-Cas systems defend against RNA phages and set the stage for its development as a tool for RNA manipulation.
