ISDA: 4BTS

Deposition Date 2013-06-19

Release Date 2013-07-17

Last Version Date 2023-12-20

Entry Detail

PDB ID:

4BTS

Keywords:

RIBOSOME

Title:

THE CRYSTAL STRUCTURE OF THE EUKARYOTIC 40S RIBOSOMAL SUBUNIT IN COMPLEX WITH EIF1 AND EIF1A

Biological Source:

Source Organism(s):

Tetrahymena thermophila SB210 (Taxon ID: 312017)
TETRAHYMENA THERMOPHILA (Taxon ID: 5911)

Expression System(s):

Escherichia coli bl21(de3)

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

3.70 Å

R-Value Free:

0.22

R-Value Work:

0.20

R-Value Observed:

0.20

Space Group:

P 1 21 1

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:TRANSLATION INITIATION FACTOR
Gene (Uniprot):TTHERM_00497990
Chain IDs:A (auth: A0), KA (auth: B0), UB (auth: C0), ED (auth: D0)
Chain Length:211
Number of Molecules:4
Biological Source:Tetrahymena thermophila SB210

UniProt ID:I7MK25 Pfam ID:PF01176

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS28E
Chain IDs:B (auth: A1), LA (auth: B1), VB (auth: C1), FD (auth: D1)
Chain Length:68
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBU6 Pfam ID:PF01200

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN S8
Chain IDs:C (auth: A2), MA (auth: B2), WB (auth: C2), GD (auth: D2)
Chain Length:208
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS6 Pfam ID:PF01201

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS7E
Chain IDs:D (auth: A3), NA (auth: B3), XB (auth: C3), HD (auth: D3)
Chain Length:197
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS5 Pfam ID:PF01251

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN S3A
Chain IDs:E (auth: A4), OA (auth: B4), YB (auth: C4), ID (auth: D4)
Chain Length:265
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBR8 Pfam ID:PF01015

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS26E
Chain IDs:F (auth: A5), PA (auth: B5), ZB (auth: C5), JD (auth: D5)
Chain Length:119
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBU4 Pfam ID:PF01283

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN S27
Chain IDs:G (auth: A6), QA (auth: B6), AC (auth: C6), KD (auth: D6)
Chain Length:81
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBU5 Pfam ID:PF01667

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS10E
Chain IDs:H (auth: A7), RA (auth: B7), BC (auth: C7), LD (auth: D7)
Chain Length:162
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS8 Pfam ID:PF03501

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS25E
Chain IDs:I (auth: A8), SA (auth: B8), CC (auth: C8), MD (auth: D8)
Chain Length:143
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBU3 Pfam ID:PF03297

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS31E
Chain IDs:J (auth: A9), TA (auth: B9), DC (auth: C9), ND (auth: D9)
Chain Length:189
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBU9 Pfam ID:PF01599

Polymer Type:polyribonucleotide
Molecule:18S ribosomal RNA
Chain IDs:K (auth: AA), UA (auth: BA), EC (auth: CA), OD (auth: DA)
Chain Length:1753
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN SA
Chain IDs:L (auth: AB), VA (auth: BB), FC (auth: CB), PD (auth: DB)
Chain Length:241
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBR9 Pfam ID:PF00318

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS3E
Chain IDs:M (auth: AC), WA (auth: BC), GC (auth: CC), QD (auth: DC)
Chain Length:243
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS1 Pfam ID:PF07650, PF00189

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS9E
Chain IDs:N (auth: AD), XA (auth: BD), HC (auth: CD), RD (auth: DD)
Chain Length:181
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS7 Pfam ID:PF00163, PF01479

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS2E
Chain IDs:O (auth: AE), YA (auth: BE), IC (auth: CE), SD (auth: DE)
Chain Length:296
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS0 Pfam ID:PF00333, PF03719

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:EIF1
Chain IDs:P (auth: AF), ZA (auth: BF), JC (auth: CF), TD (auth: DF)
Chain Length:101
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBV1 Pfam ID:PF01253

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS5E
Chain IDs:Q (auth: AG), AB (auth: BG), KC (auth: CG), UD (auth: DG)
Chain Length:200
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS3 Pfam ID:PF00177

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS22E
Chain IDs:R (auth: AH), BB (auth: BH), LC (auth: CH), VD (auth: DH)
Chain Length:130
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBU0 Pfam ID:PF00410

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS16E
Chain IDs:S (auth: AI), CB (auth: BI), MC (auth: CI), WD (auth: DI)
Chain Length:145
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT4 Pfam ID:PF00380

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS20E
Chain IDs:T (auth: AJ), DB (auth: BJ), NC (auth: CJ), XD (auth: DJ)
Chain Length:120
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT8 Pfam ID:PF00338

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS14E
Chain IDs:U (auth: AK), EB (auth: BK), OC (auth: CK), YD (auth: DK)
Chain Length:151
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT2 Pfam ID:PF00411

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN S12
Chain IDs:V (auth: AL), FB (auth: BL), PC (auth: CL), ZD (auth: DL)
Chain Length:142
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:P06147 Pfam ID:PF00164

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS18E
Chain IDs:W (auth: AM), GB (auth: BM), QC (auth: CM), AE (auth: DM)
Chain Length:155
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT6 Pfam ID:PF00416

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS29E
Chain IDs:X (auth: AN), HB (auth: BN), RC (auth: CN), BE (auth: DN)
Chain Length:55
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBU7 Pfam ID:PF00253

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS13E
Chain IDs:Y (auth: AO), IB (auth: BO), SC (auth: CO), CE (auth: DO)
Chain Length:153
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT1 Pfam ID:PF00312, PF08069

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN S24
Chain IDs:Z (auth: AP), JB (auth: BP), TC (auth: CP), DE (auth: DP)
Chain Length:149
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBU2 Pfam ID:PF01282

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS11E
Chain IDs:AA (auth: AQ), KB (auth: BQ), UC (auth: CQ), EE (auth: DQ)
Chain Length:157
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS9 Pfam ID:PF00366, PF16205

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RACK1
Chain IDs:BA (auth: AR), LB (auth: BR), VC (auth: CR), FE (auth: DR)
Chain Length:343
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBV0 Pfam ID:PF00400

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS15E
Chain IDs:CA (auth: AS), MB (auth: BS), WC (auth: CS), GE (auth: DS)
Chain Length:144
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT3 Pfam ID:PF00203

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS19E
Chain IDs:DA (auth: AT), NB (auth: BT), XC (auth: CT), HE (auth: DT)
Chain Length:155
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT7 Pfam ID:PF01090

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS12E
Chain IDs:EA (auth: AU), OB (auth: BU), YC (auth: CU), IE (auth: DU)
Chain Length:126
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT0 Pfam ID:PF01248

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS17E
Chain IDs:FA (auth: AV), PB (auth: BV), ZC (auth: CV), JE (auth: DV)
Chain Length:130
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT5 Pfam ID:PF00833

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS4E
Chain IDs:GA (auth: AW), QB (auth: BW), AD (auth: CW), KE (auth: DW)
Chain Length:259
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS2 Pfam ID:PF08071, PF00900, PF16121

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS30E
Chain IDs:HA (auth: AX), RB (auth: BX), BD (auth: CX), LE (auth: DX)
Chain Length:80
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBU8 Pfam ID:PF04758

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN S6
Chain IDs:IA (auth: AY), SB (auth: BY), CD (auth: CY), ME (auth: DY)
Chain Length:293
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBS4 Pfam ID:PF01092

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:40S RIBOSOMAL PROTEIN RPS21E
Chain IDs:JA (auth: AZ), TB (auth: BZ), DD (auth: CZ), NE (auth: DZ)
Chain Length:97
Number of Molecules:4
Biological Source:TETRAHYMENA THERMOPHILA

UniProt ID:E6PBT9 Pfam ID:PF01249

Ligand Molecules

Primary Citation

The crystal structure of the eukaryotic 40S ribosomal subunit in complex with eIF1 and eIF1A.

Weisser, M, Voigts-Hoffmann, F, Rabl, J, Leibundgut, M, Ban, N.Show

Nat. Struct. Mol. Biol. 20 1015 1017 (2013)

PMID: 23851459 DOI: 10.1038/nsmb.2622

Abstact

Eukaryotic translation initiation factors (eIFs) 1A and 1 are central players in the complex process of start-codon recognition. To improve mechanistic understanding of this process, we determined the crystal structure of the 40S ribosomal subunit in complex with eIF1A and eIF1 from Tetrahymena thermophila at a resolution of 3.7 Å. It reveals the positions of the two factors on the 40S and the conformational changes that accompany their binding.

Legend

Protein

Chemical

Disease

Primary Citation of related structures

Abstact

Feedback Form
