3WWG image
Deposition Date 2014-06-17
Release Date 2014-11-12
Last Version Date 2024-11-06
Entry Detail
PDB ID:
3WWG
Keywords:
Title:
Crystal structure of the N-glycan-deficient variant N448A of isopullulanase complexed with isopanose
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.20 Å
R-Value Free:
0.22
R-Value Work:
0.18
R-Value Observed:
0.18
Space Group:
P 1 21 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Isopullulanase
Gene (Uniprot):ipuA
Mutagens:N448A
Chain IDs:A, B, C, D
Chain Length:549
Number of Molecules:4
Biological Source:Aspergillus niger
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
ASN D ASN GLYCOSYLATION SITE
Ligand Molecules
Peptide-like Molecules
PRD_900001
Primary Citation
The side chain of a glycosylated asparagine residue is important for the stability of isopullulanase
J. Biochem. 157 225 234 (2015)
PMID: 25359784 DOI: 10.1093/jb/mvu065

Abstact

N-glycosylation has been shown to be important for the stability of some glycoproteins. Isopullulanase (IPU), a polysaccharide-hydrolyzing enzyme, is a highly N-glycosylated protein, and IPU deglycosylation results in a decrease in thermostability. To investigate the function of N-glycan in IPU, we focused on an N-glycosylated residue located in the vicinity of the active site, Asn448. The thermostabilities of three IPU variants, Y440A, N448A and S450A, were 0.5-8.4°C lower than the wild-type enzyme. The crystal structure of endoglycosidase H (Endo H)-treated N448A variant was determined. There are four IPU molecules, Mol-A, B, C and D, in the asymmetric unit. The conformation of a loop composed of amino acid residues 435-455 in Mol-C was identical to wild-type IPU, whereas the conformations of this loop in Mol-A, Mol-B and Mol-D were different from each other. These results suggest that the Asn448 side chain is primarily important for the stability of IPU. Our results indicate that mutation of only N-glycosylated Asn residue may lead to incorrect conclusion for the evaluation of the function of N-glycan. Usually, the structures of N-glycosylation sites form an extended configuration in IPU; however, the Asn448 site had an atypical structure that lacked this configuration.
