3BKN image
Deposition Date 2007-12-07
Release Date 2008-01-22
Last Version Date 2023-11-01
Entry Detail
PDB ID:
3BKN
Title:
The structure of Mycobacterial bacterioferritin
Biological Source:
Source Organism(s):
Method Details:
Experimental Method:
Resolution:
2.72 Å
R-Value Free:
0.22
R-Value Work:
0.17
R-Value Observed:
0.18
Space Group:
C 1 2 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Bacterioferritin
Gene (Uniprot):bfr
Chain IDs:A, B, C, D, E, F, G, H, I, J, K, L
Chain Length:161
Number of Molecules:12
Biological Source:Mycobacterium smegmatis str. MC2 155
Primary Citation
Bacterioferritin from Mycobacterium smegmatis contains zinc in its di-nuclear site.
Protein Sci. 17 1138 1150 (2008)
PMID: 18445621 DOI: 10.1110/ps.034819.108

Abstact

Bacterioferritins, also known as cytochrome b (1), are oligomeric iron-storage proteins consisting of 24 identical amino acid chains, which form spherical particles consisting of 24 subunits and exhibiting 432 point-group symmetry. They contain one haem b molecule at the interface between two subunits and a di-nuclear metal binding center. The X-ray structure of bacterioferritin from Mycobacterium smegmatis (Ms-Bfr) was determined to a resolution of 2.7 A in the monoclinic space group C2. The asymmetric unit of the crystals contains 12 protein molecules: five dimers and two half-dimers located along the crystallographic twofold axis. Unexpectedly, the di-nuclear metal binding center contains zinc ions instead of the typically observed iron ions in other bacterioferritins.
