1JB0 image
Deposition Date 2001-06-01
Release Date 2001-08-01
Last Version Date 2024-10-30
Entry Detail
PDB ID:
1JB0
Keywords:
Title:
Crystal Structure of Photosystem I: a Photosynthetic Reaction Center and Core Antenna System from Cyanobacteria
Biological Source:
Source Organism(s):
Method Details:
Experimental Method:
Resolution:
2.50 Å
R-Value Free:
0.21
R-Value Work:
0.19
R-Value Observed:
0.19
Space Group:
P 63
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM I P700 CHLOROPHYL
Chain IDs:A
Chain Length:755
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM I P700 CHLOROPHYL
Chain IDs:B
Chain Length:740
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM I IRON-SULFUR CEN
Chain IDs:C
Chain Length:80
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM 1 REACTION CENTRE
Chain IDs:D
Chain Length:138
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM 1 REACTION CENTRE
Chain IDs:E
Chain Length:75
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM 1 REACTION CENTRE
Chain IDs:F
Chain Length:164
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM 1 REACTION CENTRE
Chain IDs:G (auth: I)
Chain Length:38
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM 1 REACTION CENTRE
Chain IDs:H (auth: J)
Chain Length:41
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM 1 REACTION CENTRE
Chain IDs:I (auth: K)
Chain Length:83
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM 1 REACTION CENTRE
Chain IDs:J (auth: L)
Chain Length:154
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM 1 REACTION CENTRE
Chain IDs:K (auth: M)
Chain Length:31
Number of Molecules:1
Biological Source:Synechococcus elongatus
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PHOTOSYSTEM I SUBUNIT PSAX
Chain IDs:L (auth: X)
Chain Length:35
Number of Molecules:1
Biological Source:Synechococcus elongatus
Primary Citation

Abstact

Life on Earth depends on photosynthesis, the conversion of light energy from the Sun to chemical energy. In plants, green algae and cyanobacteria, this process is driven by the cooperation of two large protein-cofactor complexes, photosystems I and II, which are located in the thylakoid photosynthetic membranes. The crystal structure of photosystem I from the thermophilic cyanobacterium Synechococcus elongatus described here provides a picture at atomic detail of 12 protein subunits and 127 cofactors comprising 96 chlorophylls, 2 phylloquinones, 3 Fe4S4 clusters, 22 carotenoids, 4 lipids, a putative Ca2+ ion and 201 water molecules. The structural information on the proteins and cofactors and their interactions provides a basis for understanding how the high efficiency of photosystem I in light capturing and electron transfer is achieved.
