9W2R image
Deposition Date 2025-07-28
Release Date 2026-04-01
Last Version Date 2026-04-01
Entry Detail
PDB ID:
9W2R
Keywords:
MOTOR PROTEIN
Title:
Cryo-EM structure of FoF1-ATPase monomer state 1 on the bovine heart submitochondrial particles (FoF1-1)
Biological Source:
Source Organism(s):
Bos taurus (Taxon ID: 9913)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.40 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9W2R validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):MT-ATP8
Chain IDs:A (auth: 8)
Chain Length:66
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P03929 Pfam ID:PF00895
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1A
Chain IDs:B (auth: A), C (auth: B), D (auth: C)
Chain Length:510
Number of Molecules:3
Biological Source:Bos taurus
UniProt ID:P19483 Pfam ID:PF02874, PF00006, PF00306 EC:7.1.2.2
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex cat
Gene (Uniprot):ATP5F1B
Chain IDs:E (auth: D), F (auth: E), G (auth: F)
Chain Length:482
Number of Molecules:3
Biological Source:Bos taurus
UniProt ID:P00829 Pfam ID:PF02874, PF00006, PF22919
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1C
Chain IDs:H (auth: G)
Chain Length:273
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P05631 Pfam ID:PF00231
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1D
Chain IDs:I (auth: H)
Chain Length:146
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P05630 Pfam ID:PF02823, PF21335
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(1) complex sub
Gene (Uniprot):ATP5F1E
Chain IDs:J (auth: I)
Chain Length:50
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P05632 Pfam ID:PF04627
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATPase inhibitor, mitochondri
Gene (Uniprot):ATP5IF1
Chain IDs:K (auth: J)
Chain Length:60
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P01096 Pfam ID:PF04568
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MC1
Chain IDs:L (auth: K), M (auth: L), N (auth: M), O (auth: N), P (auth: O), Q (auth: P), R (auth: Q), S (auth: R)
Chain Length:75
Number of Molecules:8
Biological Source:Bos taurus
UniProt ID:P32876 Pfam ID:PF00137
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PO
Chain IDs:T (auth: S)
Chain Length:190
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P13621 Pfam ID:PF00213
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):MT-ATP6
Chain IDs:U (auth: a)
Chain Length:510
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P00847 Pfam ID:PF00119
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PB
Chain IDs:V (auth: b)
Chain Length:214
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P13619 Pfam ID:PF05405
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PD
Chain IDs:W (auth: d)
Chain Length:482
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P13620 Pfam ID:PF05873
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5ME
Chain IDs:X (auth: e)
Chain Length:482
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:Q00361 Pfam ID:PF05680
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MF
Chain IDs:Y (auth: f)
Chain Length:482
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:Q28851 Pfam ID:PF10206
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MG
Chain IDs:Z (auth: g)
Chain Length:273
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:Q28852 Pfam ID:PF04718
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase peripheral stalk
Gene (Uniprot):ATP5PF
Chain IDs:AA (auth: h)
Chain Length:146
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P02721 Pfam ID:PF05511
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MJ
Chain IDs:BA (auth: j)
Chain Length:60
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P14790 Pfam ID:PF08039
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP synthase F(0) complex sub
Gene (Uniprot):ATP5MK
Chain IDs:CA (auth: k)
Chain Length:75
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:Q3ZBI7 Pfam ID:PF14960
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
M3L L LYS modified residue
Ligand Molecules
ADP
ATP
MG
Primary Citation
Structures of respiratory supercomplexes and ATP synthase oligomers in mammalian mitochondrial inner membrane.
Nat Commun ? ? ? (2026)
PMID: 41844608 DOI: 10.1038/s41467-026-70578-x
