9V9E image
Deposition Date 2025-05-30
Release Date 2026-04-08
Last Version Date 2026-04-08
Entry Detail
PDB ID:
9V9E
Keywords:
PROTEIN FIBRIL
Title:
Cryo-EM structure of human RIPK1 DD filament
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
2.87 Å
Aggregation State:
FILAMENT
Reconstruction Method:
HELICAL
9V9E validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Receptor-interacting serine/t
Gene (Uniprot):RIPK1
Chain IDs:A, B, C, D, E, F, G, H, I, J, K, L, M, N, O, P, Q, R, S, T
Chain Length:115
Number of Molecules:20
Biological Source:Homo sapiens
UniProt ID:Q13546 Pfam ID:PF00531 EC:2.7.10.2
Ligand Molecules
NA
Primary Citation
Electric dipole moment drives the dynamics of the TNFR1 complex I signalosome
Nature ? ? ? (2026)
DOI: 10.1038/s41586-026-10304-1
Primary Citation of related structures
9V9E
