9UD3 image
Deposition Date 2025-04-06
Release Date 2025-06-25
Last Version Date 2025-06-25
Entry Detail
PDB ID:
9UD3
Title:
Cryo-EM structure of Na+-translocating NADH-ubiquinone oxidoreductase NqrB-T236Y mutant from Vibrio cholerae
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
3.80 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Na(+)-translocating NADH-quin
Gene (Uniprot):nqrA
Chain IDs:A
Chain Length:446
Number of Molecules:1
Biological Source:Vibrio cholerae O395
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Na(+)-translocating NADH-quin
Gene (Uniprot):nqrB
Mutagens:T236Y
Chain IDs:B
Chain Length:415
Number of Molecules:1
Biological Source:Vibrio cholerae O395
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Na(+)-translocating NADH-quin
Gene (Uniprot):nqrC
Chain IDs:C
Chain Length:257
Number of Molecules:1
Biological Source:Vibrio cholerae O395
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Na(+)-translocating NADH-quin
Gene (Uniprot):nqrD
Chain IDs:D
Chain Length:210
Number of Molecules:1
Biological Source:Vibrio cholerae O395
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Na(+)-translocating NADH-quin
Gene (Uniprot):nqrE
Chain IDs:E
Chain Length:198
Number of Molecules:1
Biological Source:Vibrio cholerae O395
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Na(+)-translocating NADH-quin
Gene (Uniprot):nqrF
Chain IDs:F
Chain Length:414
Number of Molecules:1
Biological Source:Vibrio cholerae O395
Primary Citation
The Na + -pumping mechanism driven by redox reactions in the NADH-quinone oxidoreductase from Vibrio cholerae relies on dynamic conformational changes.
Biorxiv ? ? ? (2025)
PMID: 40501732 DOI: 10.1101/2025.06.01.656757

Abstact

The Na + -pumping NADH-quinone oxidoreductase (Na + -NQR) is a key respiratory enzyme in many marine and pathogenic bacteria that couples electron transfer to Na + -pumping across the membrane. Earlier X-ray and cryo-EM structures of Na + -NQR from Vibrio cholerae suggested that the subunits harboring redox cofactors undergo conformational changes during catalytic turnover. However, these proposed rearrangements have not yet been confirmed. Here, we have identified at least five distinct conformational states of Na + -NQR using: mutants that lack specific cofactors, specific inhibitors or low-sodium conditions. Molecular dynamics simulations based on these structural insights indicate that 2Fe-2S reduction in NqrD/E plays a crucial role in triggering Na + translocation by driving structural rearrangements in the NqrD/E subunits, which subsequently influence NqrC and NqrF positioning. This study provides the first structural insights into the mechanism of Na + translocation coupled to electron transfer in Na⁺-NQR.
