ISDA: 9COC

Deposition Date 2024-07-16

Release Date 2026-03-18

Last Version Date 2026-03-18

Entry Detail

PDB ID:

9COC

Keywords:

STRUCTURAL PROTEIN

Title:

Two protofilament structure of alpha1B and betaI/IVb microtubule bound to GDP

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

2.90 Å

Aggregation State:

FILAMENT

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Tubulin alpha-1B chain
Gene (Uniprot):TUBA1B
Chain IDs:E (auth: A), F (auth: D), G (auth: C), H (auth: I)
Chain Length:451
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:P68363 Pfam ID:PF00091, PF03953

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Tubulin beta chain
Gene (Uniprot):TUBB
Chain IDs:A (auth: B), B (auth: E), C (auth: F), D (auth: K)
Chain Length:444
Number of Molecules:4
Biological Source:Homo sapiens

UniProt ID:P07437 Pfam ID:PF00091, PF03953

Ligand Molecules
